/alethic-scientific-figure — Scientific Figures

A figure is not a data dump — it is a graphical interface between people and data. Treat every figure as a UI/UX design problem: you have a user (the reader), a context (journal, slide deck, poster), and a message to transmit with maximum signal-to-noise ratio.

Above all else, show the data.

These principles are distilled from Rougier, Droettboom & Bourne, "Ten Simple Rules for Better Figures" (PLoS Comput. Biol. 2014) and Tufte's principles of graphical excellence. The matplotlib configuration uses a custom AFP institutional color palette with perceptually optimized ordering.

The user's input is: $ARGUMENTS

Bundled resources (read on demand):

•references/color-palette.md — Full qualitative cycle, AFP colormaps, shade families, semantic shorthand, seaborn fallbacks
•references/presentation-override.md — Slide and poster rcParams overrides
•scripts/register_colormaps.py — Register all AFP colormaps with matplotlib

Core Principles

Apply these in order. Each principle constrains downstream decisions.

1. Audience First

Before writing a single line of plotting code, determine who will read the figure. This drives every subsequent choice.

Audience	Design implications
Self / collaborators	Dense is fine; shared context assumed
Journal reviewers & readers	Self-explanatory; complete axis labels, units, legends
Oral presentation	Simplified; thick lines, large fonts, high contrast, no fine detail
General public	Single salient message; approximation acceptable; minimal jargon

When the user doesn't specify, default to journal-quality: self-contained, fully labeled, and readable at single-column width (~3.3 in / 84 mm for Nature).

2. One Figure, One Message

Identify the single core message before choosing a plot type. The message drives everything: which data to include, what to emphasize, what to suppress. If a figure tries to say two things, it says neither clearly — split it.

Ask yourself (or the user): "What should the reader conclude at first glance?"

3. Match the Medium

Never reuse the same figure across media without adaptation.

For papers (long viewing time):

•Fine detail is acceptable
•Use thin lines (0.5-1 pt), font sizes 7 pt (Nature standard)
•Exploit captions for explanation
•Insets and zoomed panels add value

For slides (time-limited, viewed from distance):

•Strip to essentials — fewer curves, fewer ticks, no fine structure
•Thicken everything: lines >= 1.5 pt, fonts >= 14 pt, markers >= 6 pt
•High-contrast colors on dark or light backgrounds
•No vertical text; minimize legend boxes (label curves directly)
•Add visual anchors (colored boxes, dashed reference lines)
•For slide/poster rcParams, read references/presentation-override.md

For posters:

•Intermediate between paper and slide
•Must be readable at ~1 m distance

4. Captions Are Mandatory

Always generate a caption suggestion alongside the figure. A good caption:

•Explains how to read the figure (what axes mean, what colors encode)
•Points out the key takeaway
•Provides numerical precision that the graphic cannot convey
•Anticipates reader questions

5. Never Trust Defaults — Direct Labeling over Legends

Default settings in any plotting library are generic compromises. The style block below replaces them with a curated baseline. Beyond that, always verify:

•Tick density: Reduce to the minimum needed.
•Font sizes: Scale to the medium (7 pt for Nature, >=14 pt for slides).
•Line widths & marker sizes: 1.0 pt data, 0.5 pt axes in journal figures.
•Figure size & aspect ratio: Set explicitly for the target column width.
•
Legend placement: Prefer direct annotation on curves over a separate legend box. Legends force an eye-travel penalty (data -> legend -> back). Place labels at the end of each curve:
python
```
ax.text(x[-1], y[-1], "  Series A", va="center", fontsize=7,
        color=line.get_color())
```
For dense plots with overlapping endpoints, use the adjustText library for automated label placement. Fall back to a legend only when direct annotation would create clutter worse than the lookup cost.

6. Use Color with Intent

Color is the most powerful — and most abused — visual channel.

Color assignment strategy (priority order):

•Semantic mapping: If the data has natural color associations, use them. Override the cycle explicitly (e.g. red/blue for hot/cold).
•Cycle through the palette: When no semantics exist, use the AFP color cycle in order. The first 6 colors have good mutual contrast.
•Highlight by exception: One colored series among many; rest in light gray (#d0d0d0).

Colormap defaults (all AFP maps are CIELAB-linearized):

•Sequential: viridis for maximum perceptual uniformity, or AFP alternatives (afp_blue, afp_bluegreen) for brand consistency. All AFP sequential maps have uniform L* ramps (Delta-L* RMS < 0.5).
•Diverging: afp_KbOr (kobalt<->orange, 144 deg hue separation under deuteranopia — best CVD safety). Multi-hue options: afp_BgRo (bluegreen<->redorange) for rich hue variation. Avoid afp_RdGn and afp_GnOr (both fail CVD).
•Categorical: AFP qualitative cycle (default) or seaborn colorblind.
•Never use jet / rainbow for continuous data.
•See references/color-palette.md for the full set (28 maps x 2 with reversed _r variants), selection guide, and CVD analysis.

To register all AFP colormaps with matplotlib, run:

python

import sys, os
skill_dir = os.path.dirname(os.path.abspath(__file__))  # adjust as needed
sys.path.insert(0, os.path.join(skill_dir, "scripts"))
import register_colormaps; register_colormaps.register_all()

Color-blind safety (~8% of males):

•Avoid red-green as the sole distinguishing pair.
•Supplement qualitative colors with line style or marker shape.
•For full palette hex values, seaborn fallbacks, and CVD analysis, read references/color-palette.md.

When there are many (>4) overlapping series: Ask the user which strategy to use — small multiples (see below), highlight-by-exception, or full cycle with legend. Do not assume a default; the best choice depends on the message.

7. Do Not Mislead

Show data variation, not design variation. Visual differences should come from the data, never from gratuitous design choices (varying fonts, line styles for no reason, inconsistent scales).

Lie Factor (Tufte): the ratio of the size of an effect shown in the graphic to the size of the effect in the data. Honest graphics have a Lie Factor near 1.0; anything outside 0.95-1.05 warrants scrutiny. Check this whenever encoding value as visual area, length, or angle.

Common traps to actively avoid:

•Truncated axes: Bar charts must start at zero. Line plots may truncate if zero is meaningless, but label clearly.
•Area vs. radius: Map value -> area, not value -> radius. The s parameter in scatter() is already points-squared, so pass values directly.
•Pie charts: Avoid entirely in scientific contexts. Use bar or dot plots.
•3D charts: Avoid for quantitative comparison. Use only for genuine 3D data (surface plots of 2D fields).
•Dual y-axes: Use with extreme caution. Clearly label and color-code.
•Aspect ratio manipulation: Choose ratios that honestly represent variability.

8. Eliminate Chartjunk — Layering & Separation

Every visual element must earn its place. Remove anything that doesn't carry information: colored backgrounds, decorative gridlines, redundant labels, excessive tick marks, 3D effects on 2D data.

Data density (Tufte): entries in the data matrix divided by the area of the graphic. Most published figures are sparse (<10 entries/cm-squared); the best achieve thousands. After removing chartjunk, ask whether you can add information without adding clutter.

The 1+1=3 problem (Tufte, via Albers): two visual elements create a third perceptual artifact at their boundary. When that artifact is noise rather than information, the design fails. Actionable in matplotlib:

•Muted gridlines: color="#d0d0d0", linewidth=0.3, zorder=0
•Reference elements behind data: set zorder explicitly
•Confidence bands: alpha=0.15-0.25, same color as the parent line
•Spine color lighter than data lines: ax.spines[...].set_color("#999999")

9. Message Over Aesthetics

Scientific figures serve communication first. Beauty is welcome but never at the expense of clarity. Follow domain conventions where they exist.

10. Use the Right Tool

Tool	Best for
matplotlib	Publication-quality 2D; full control; Python ecosystem
seaborn	Statistical plots with sane defaults on top of matplotlib
pgfplots / TikZ	LaTeX-native; perfect font matching; programmatic
plotly	Interactive exploration; web dashboards
R / ggplot2	Statistical graphics with grammar-of-graphics approach

When generating code, prefer matplotlib unless the user specifies otherwise.

11. Small Multiples

Tufte's most powerful technique for complex data. Repeat the same plot frame across a grid, varying one parameter per panel. The reader's eye learns the frame once and then reads the data across panels.

When to prefer small multiples over overlaid curves:

•More than 4 series that would overlap or create spaghetti
•The message is "each behaves differently" rather than "compare these two"
•Different panels represent different experimental conditions or time windows

Implementation:

python

fig, axes = plt.subplots(nrows, ncols, sharex=True, sharey=True,
                          figsize=(ncols*2.5, nrows*2))
fig.align_ylabels()  # critical for honest visual comparison

Shared axes are essential — without them the panels lie about relative magnitudes. Label only the outer axes to minimize ink. Add a single shared colorbar or legend outside the grid if needed.

12. Micro/Macro Readings

The best graphics work at two scales simultaneously (Tufte, Envisioning Information). At the macro level the reader grasps the overall pattern; at the micro level they can extract individual data points or values.

Design for both:

•Macro: overall line shape, trend direction, dominant features
•Micro: ax.annotate() for key points (minima, crossings, outliers), ax.inset_axes() for zoomed regions, minor ticks for interpolation
•Choose line widths and marker sizes that serve both scales — thick enough to see trends, thin enough to resolve close points

13. Sparklines

Tufte's invention (Beautiful Evidence): tiny, word-sized graphics that live inline with text or inside table cells. A sparkline conveys a trend, range, or distribution in the space of a word — no axes, no labels, just the data shape. Underused in scientific papers, but powerful for comparison tables (e.g., noise spectra across sensor variants, time-series thumbnails in a parameter sweep).

Implementation:

python

fig, ax = plt.subplots(figsize=(1.5, 0.3))
ax.plot(x, y, color="#2e2cb8", linewidth=0.8)
ax.fill_between(x, y, alpha=0.1, color="#2e2cb8")
ax.axis("off")
fig.subplots_adjust(left=0, right=1, top=1, bottom=0)
fig.savefig("sparkline.png", dpi=300, transparent=True)

For embedding in LaTeX tables, save as tight PNGs or PDFs and use \includegraphics[height=1em]{sparkline.png}. For multi-row comparison tables, ensure all sparklines share the same y-limits so visual heights are comparable across rows.

Implementation Checklist

Before delivering any figure, verify:

Base Style Configuration

This block merges scienceplots styles science + nature + no-latex into a standalone rcParams.update() requiring no external dependencies beyond matplotlib. The line color cycle uses the AFP institutional palette.

Apply at the top of every plotting script. Adjust figure.figsize for double-column (6.6 in) or presentation as needed.

python

import matplotlib.pyplot as plt

plt.rcParams.update({
    # --- Figure geometry ---
    "figure.figsize": (3.3, 2.5),
    "figure.dpi": 150,
    "savefig.dpi": 300,
    "savefig.bbox": "tight",
    "savefig.pad_inches": 0.05,

    # --- Font: Nature requires sans-serif ---
    "font.family": "sans-serif",
    "font.sans-serif": [
        "DejaVu Sans", "Arial", "Helvetica",
        "Lucida Grande", "Verdana", "sans-serif",
    ],
    "font.size": 7,
    "axes.labelsize": 9,
    "axes.titlesize": 7,
    "xtick.labelsize": 7,
    "ytick.labelsize": 7,
    "legend.fontsize": 7,

    # --- Math text (no LaTeX dependency) ---
    "text.usetex": False,
    "axes.formatter.use_mathtext": True,
    "mathtext.fontset": "dejavusans",

    # --- Axes & spines ---
    "axes.linewidth": 0.5,

    # --- Ticks: inward, visible on all sides, minor ticks on ---
    "xtick.direction": "in",
    "xtick.major.size": 3,
    "xtick.major.width": 0.5,
    "xtick.minor.size": 1.5,
    "xtick.minor.width": 0.5,
    "xtick.minor.visible": True,
    "xtick.top": True,

    "ytick.direction": "in",
    "ytick.major.size": 3,
    "ytick.major.width": 0.5,
    "ytick.minor.size": 1.5,
    "ytick.minor.width": 0.5,
    "ytick.minor.visible": True,
    "ytick.right": True,

    # --- Lines & markers ---
    "lines.linewidth": 1.0,
    "lines.markersize": 3,
    "grid.linewidth": 0.5,
    "axes.grid": False,

    # --- Legend ---
    "legend.frameon": False,

    # --- Color cycle: AFP palette (10 colors) ---
    # Ordered for warm/cool alternation; min adjacent delta-E = 98 (CIEDE76).
    "axes.prop_cycle": plt.cycler("color", [
        "#2e2cb8",  # C0 blue
        "#db002b",  # C1 red
        "#1f8a70",  # C2 green/teal
        "#fd7400",  # C3 orange
        "#1c809e",  # C4 blueberry
        "#bedb43",  # C5 limegreen
        "#9b2f5c",  # C6 pink
        "#fabd1e",  # C7 gold
        "#5c2d99",  # C8 violet
        "#2c6b2f",  # C9 forest
    ]),

    # --- Default colormap ---
    "image.cmap": "viridis",
})

Session Tracking

After generating a figure, persist the session for reproducibility.

•
Project detection: Same as /alethic-solve — check for .git in cwd or parents. Use Bash:
bash
```
git rev-parse --show-toplevel 2>/dev/null || echo ""
```
If found, use cwd as {project_root} and proceed. If not found, skip session tracking entirely (figures are delivered inline).
•
Create session directory: Generate a slug from the figure description (lowercase, strip non-alphanumeric to hyphens, collapse runs, truncate to 40 chars), then:
bash
```
HEX=$(head -c2 /dev/urandom | xxd -p)
SESSION_ID="${SLUG}-$(date +%Y%m%d)-${HEX}"
SESSION_DIR="{project_root}/.alethic/${SESSION_ID}"
mkdir -p "${SESSION_DIR}"
```

•

Save files:

•Copy the plotting script to {session_dir}/output.py
•Copy the figure file to {session_dir}/output.{ext} (pdf, png, or svg)
•Write {session_dir}/session.json:

json

{
  "schema_version": 1,
  "session_id": "{session_id}",
  "problem": "{figure description}",
  "domain": "figure",
  "skill": "alethic-scientific-figure",
  "status": "completed",
  "output_file": "output.{ext}",
  "created_at": "{ISO 8601 timestamp}",
  "completed_at": "{ISO 8601 timestamp}"
}

•

Append to .alethic/sessions.jsonl:

json

{"session_id":"{session_id}","problem":"{figure description}","domain":"figure","status":"completed","created_at":"{created_at}","completed_at":"{completed_at}"}

Use Bash to append: echo '{json_line}' >> {project_root}/.alethic/sessions.jsonl

•

Print breadcrumb:

code

**Session:**  `.alethic/{session_id}/`
**Script:**   `.alethic/{session_id}/output.py`
**Figure:**   `.alethic/{session_id}/output.{ext}`

Note: Session tracking is best-effort. If directory creation fails (permissions, non-project context), deliver the figure normally without persisting session state.
