Writing Pivot Stages

Overview

Pivot stages are pure Python functions declaring file I/O via type annotations. The framework handles loading, saving, caching, and DAG construction.

Core principle: Annotations handle all file I/O. Functions receive pre-loaded data and return data to be saved.

Imports

python

from typing import Annotated, TypedDict
from pivot.outputs import Dep, Out, Metric, Plot, PlaceholderDep, IncrementalOut, DirectoryOut
from pivot.loaders import CSV, JSON, JSONL, YAML, Text, Pickle, PathOnly, MatplotlibFigure
from pivot.loaders import Reader, Writer, Loader  # Base classes for custom loaders
from pivot.stage_def import StageParams
from pivot.pipeline import Pipeline

Stage Anatomy

python

class MyParams(StageParams):
    threshold: float = 0.5

class MyOutputs(TypedDict):
    result: Annotated[pd.DataFrame, Out("output.csv", CSV())]
    metrics: Annotated[dict, Metric("metrics.json")]

def my_stage(
    params: MyParams,
    data: Annotated[pd.DataFrame, Dep("input.csv", CSV())],
) -> MyOutputs:
    filtered = data[data["score"] > params.threshold]
    return {"result": filtered, "metrics": {"count": len(filtered)}}

pipeline = Pipeline("my_pipeline")
pipeline.register(my_stage, params=MyParams(threshold=0.3))

Single output: Annotate return directly instead of TypedDict:

python

def transform(
    data: Annotated[pd.DataFrame, Dep("input.csv", CSV())],
) -> Annotated[pd.DataFrame, Out("output.csv", CSV())]:
    return data.dropna()

Loader Hierarchy

The loader system has three base classes:

Base Class	Methods	Use Case
`Reader[R]`	`load() -> R`	Read-only (dependencies)
`Writer[W]`	`save(data: W, ...)`	Write-only (outputs)
`Loader[W, R]`	Both `load()` and `save()`	Bidirectional (incremental outputs)

Type constraints:

•Dep.loader accepts Reader[R] (or Loader, which extends Reader)
•Out.loader accepts Writer[W] (or Loader, which extends Writer)
•IncrementalOut.loader requires Loader[W, R] (needs both read and write)
•DirectoryOut.loader accepts Writer[T]

Built-in Loaders

Loader	Base	Data Type	Options	`empty()`
`CSV()`	`Loader`	DataFrame	`index_col`, `sep`, `dtype`	Yes
`JSON()`	`Loader`	dict/list	`indent=2`, `empty_factory=dict`	Yes
`JSONL()`	`Loader`	list[dict]	—	Yes
`YAML()`	`Loader`	dict/list	`empty_factory=dict`	Yes
`Text()`	`Loader`	str	—	Yes
`Pickle()`	`Loader`	Any	`protocol`	No
`PathOnly()`	`Loader`	Path	—	No
`MatplotlibFigure()`	`Writer`	Figure	`dpi=150`, `bbox_inches`, `transparent`	N/A

Notes:

•Loaders with empty() support are required for IncrementalOut.
•MatplotlibFigure is Writer[Figure] (write-only) because images cannot be loaded back as Figure objects.

Output Types

Type	Default Cache	Git-Tracked	Use Case
`Out`	True	No	Standard outputs
`Metric`	False	Yes	Small JSON metrics (path must end `.json`)
`Plot`	True	No	Visualizations
`IncrementalOut`	True	No	Builds on previous run's output
`DirectoryOut`	True	No	Dynamic set of files in directory

Multi-File Dependencies/Outputs

python

# Variable-length list (count can change between runs)
shards: Annotated[list[pd.DataFrame], Dep(["a.csv", "b.csv"], CSV())]

# Fixed-length tuple (exact count enforced)
pair: Annotated[tuple[pd.DataFrame, pd.DataFrame], Dep(("x.csv", "y.csv"), CSV())]

IncrementalOut

Previous output restored from cache before stage runs. Use for append-only state:

python

class CacheOutputs(TypedDict):
    cache: Annotated[dict, IncrementalOut("cache.json", JSON())]

def incremental_stage(
    cache: Annotated[dict | None, IncrementalOut("cache.json", JSON())],  # Input
) -> CacheOutputs:
    existing = cache or {}
    existing["new_key"] = "value"
    return {"cache": existing}

Rules: Same path in input and output annotations. Loader must support empty().

DirectoryOut

For dynamic file sets determined at runtime:

python

class TaskOutputs(TypedDict):
    results: Annotated[dict[str, dict], DirectoryOut("results/", JSON())]

def process_tasks(...) -> TaskOutputs:
    return {"results": {
        "task_a.json": {"accuracy": 0.95},
        "task_b.json": {"accuracy": 0.87},
    }}

Rules:

•Path must end with /
•Keys must have extensions, no path traversal (../), no absolute paths
•Dict must be non-empty

PlaceholderDep

Dependency with no default path—must be overridden at registration:

python

def compare(
    baseline: Annotated[pd.DataFrame, PlaceholderDep(CSV())],
) -> CompareOutputs: ...

pipeline.register(compare, dep_path_overrides={"baseline": "model_a/results.csv"})

Matplotlib Plots

Plots require all three parts in the annotation:

python

Annotated[
    matplotlib.figure.Figure,              # 1. The type (must be Figure, not Axes)
    Plot("plots/my_plot.png",              # 2. The output type (Plot, not Out)
         MatplotlibFigure(dpi=150))        # 3. The loader (required, handles save/close)
]

Note: MatplotlibFigure is a Writer[Figure] (not a full Loader) because saved images cannot be loaded back as matplotlib Figure objects. It only has a save() method.

Full example:

python

import matplotlib.figure
import matplotlib.pyplot as plt

class PlotOutputs(TypedDict):
    plot: Annotated[matplotlib.figure.Figure, Plot("plots/my_plot.png", MatplotlibFigure())]

def make_plot(
    data: Annotated[pd.DataFrame, Dep("input.csv", CSV())],
) -> PlotOutputs:
    fig, ax = plt.subplots()
    ax.plot(data["x"], data["y"])
    return {"plot": fig}  # Return Figure, not Axes. Framework saves and closes.

Path Overrides

python

pipeline.register(my_stage, name="my_stage@v2", out_path_overrides={"result": "v2/output.csv"})

Custom Loaders

Create custom loaders by extending the appropriate base class:

Reader (read-only) - for dependencies that only need loading:

python

import dataclasses
import pathlib
from pivot.loaders import Reader

@dataclasses.dataclass(frozen=True)
class ImageReader(Reader[np.ndarray]):
    def load(self, path: pathlib.Path) -> np.ndarray:
        from PIL import Image
        return np.array(Image.open(path))

Writer (write-only) - for outputs that cannot be loaded back:

python

@dataclasses.dataclass(frozen=True)
class HTMLWriter(Writer[str]):
    def save(self, data: str, path: pathlib.Path) -> None:
        path.write_text(data)

Loader (bidirectional) - for IncrementalOut or symmetric I/O:

python

@dataclasses.dataclass(frozen=True)
class NPY(Loader[np.ndarray, np.ndarray]):
    def load(self, path: pathlib.Path) -> np.ndarray:
        return np.load(path)

    def save(self, data: np.ndarray, path: pathlib.Path) -> None:
        np.save(path, data)

    def empty(self) -> np.ndarray:  # Required for IncrementalOut
        return np.array([])

Rules:

•Use @dataclasses.dataclass(frozen=True) for immutability and pickling
•Loaders must be module-level classes (not closures)
•Implement empty() only if the loader will be used with IncrementalOut

StageParams Defaults

Pydantic deep-copies all defaults (lists, dicts, nested models, TypedDicts). Never use default_factory for mutable defaults — use plain values:

python

# WRONG — unnecessary complexity
class MyParams(StageParams):
    exclude: list[str] = pydantic.Field(default_factory=list)
    styling: dict[str, Any] = pydantic.Field(default_factory=dict)
    percents: list[int] = pydantic.Field(default_factory=lambda: [50, 80])
    plots: PlotParams = pydantic.Field(default_factory=PlotParams)

# CORRECT — Pydantic handles all of these safely
class MyParams(StageParams):
    exclude: list[str] = []
    styling: dict[str, Any] = {}
    percents: list[int] = [50, 80]
    plots: PlotParams = PlotParams()

Only use pydantic.Field() when you need its features (alias, description, ge, etc.), not just for defaults.

Critical Rules

•All paths relative to project root — not relative to stage file
•No manual file I/O — no pd.read_csv(), to_csv(), open() in stage body
•File paths in annotations, not params — StageParams for config only
•No default_factory for mutable defaults — Pydantic deep-copies; use = [], = {}, = Model() directly
•Stages must be module-level functions — lambdas/closures fail pickling
•TypedDict outputs must be module-level — not defined inside functions

Running Stages

bash

pivot repro                  # Run entire pipeline (DAG-aware)
pivot repro my_stage         # Run my_stage AND all dependencies
pivot repro --dry-run        # Validate DAG without executing

pivot run my_stage           # Run ONLY my_stage (no dependency resolution)

Pipeline Composition

Include stages from sub-pipelines while preserving their state directories:

python

# Define sub-pipeline
preprocessing = Pipeline("preprocessing")
preprocessing.register(clean_data, name="clean")
preprocessing.register(normalize, name="normalize")

# Include in main pipeline
main = Pipeline("main")
main.include(preprocessing)  # Deep-copies stages, preserves state_dir
main.register(train, name="train")  # Can depend on preprocessing outputs

Behavior:

•Included stages keep their original state_dir (for lock files, state.db)
•Stages are deep-copied: mutations don't propagate between pipelines
•include() is a point-in-time snapshot; later registrations in source don't propagate
•Including empty pipeline is a no-op
•Including same pipeline twice raises (name collision)
•Transitive: if B includes C, then A includes B, A gets C's stages (already in B's registry)

Rules:

•Stage name collisions raise PipelineConfigError
•Cannot include a pipeline into itself

Security Note: Only include pipelines from trusted sources. Included stages execute with the same privileges as your pipeline.

Testing

Pass data directly (annotations are bypassed):

python

def test_my_stage():
    result = my_stage(
        params=MyParams(threshold=0.5),
        data=pd.DataFrame({"score": [0.3, 0.7, 0.9]}),
    )
    assert len(result["result"]) == 2

Common Errors

Error	Cause	Fix
`cannot pickle`	Closure/lambda as stage	Move to module-level function
`PlaceholderDep requires override`	Missing path	Add `dep_path_overrides`
`IncrementalOut path mismatch`	Input/output paths differ	Use same path in both annotations
`DirectoryOut path must end with '/'`	Missing trailing slash	Add `/` to path
`DirectoryOut key must have extension`	Key like `"task_a"`	Use `"task_a.json"`
`loader is required`	`Out("file.json")` without loader	Add loader: `Out("file.json", JSON())`
`TypedDict field missing Out annotation`	Field without `Out`/`Metric`/`Plot`	Add annotation to all fields
`stage 'X' already exists`	Name collision in `include()`	Rename stage with `name=` at registration
`cannot include itself`	Self-include attempted	Use a separate Pipeline instance

Checklist

• No manual file I/O in stage function
• No file paths in StageParams
• No default_factory in StageParams (use plain defaults: = [], = {}, = Model())
• All Dep/Out paths relative to project root
• Stage is module-level function (not closure)
• TypedDict outputs defined at module level
• Ran pivot run and verified outputs exist
