SKILL.md

Helps with Spring Boot backend development following Algorena's domain-driven architecture.

Usage: /spring-boot <task description>

Examples:

  • •/spring-boot add tournaments domain
  • •/spring-boot add endpoint to get bot by game type
  • •/spring-boot add validation to match creation

What this skill does:

Project Understanding

  • •Follows the domain-driven design pattern: domain/ → controllers/ → application/ → data/
  • •Uses the established package structure: com.algorena.{domain}.{layer}
  • •Understands the three main domains: bots/, games/, users/
  • •Follows shared patterns from common/ (exceptions, base entities, config)

Encapsulation Philosophy

CRITICAL: Never use @Setter on domain entities or value objects.

Entities should protect their invariants through explicit business methods:

java
// WRONG - exposes internal state
@Setter
private boolean active;

// RIGHT - encapsulated business operation
public void activate() {
    this.active = true;
}

public void deactivate() {
    this.active = false;
}

Business methods should:

  • •Have meaningful names that describe the business operation (markAsDeleted() not setDeleted(true))
  • •Validate inputs and enforce invariants
  • •Throw IllegalArgumentException for invalid operations
  • •Combine related state changes (e.g., markAsDeleted() deactivates AND clears sensitive data)

The only exception is BaseEntity, which uses @Setter because Spring Data JPA auditing requires it for timestamp fields.

Code Generation Patterns

Entities:

  • •Extends BaseEntity for automatic created and lastUpdated timestamps
  • •Uses Lombok: @Getter, @NoArgsConstructor, @AllArgsConstructor, @Builder
  • •NEVER use @Setter - entities are encapsulated; state changes happen through explicit business methods (e.g., activate(), updateDetails(), markAsDeleted())
  • •Uses @Entity and @Table with explicit table names
  • •Uses JSpecify @Nullable for nullable fields
  • •Implements business logic methods (activate/deactivate, update operations)
  • •Uses NullAway null-safety annotations
  • •For DDD aggregates, restrict constructor access: @NoArgsConstructor(access = AccessLevel.PROTECTED), @AllArgsConstructor(access = AccessLevel.PRIVATE), @Builder(access = AccessLevel.PACKAGE)
  • •Use static factory methods for complex creation (e.g., User.createFromOAuth2(userInfo, username))

BaseEntity:

  • •Located at com.algorena.common.domain.BaseEntity
  • •Provides created and lastUpdated fields (Java LocalDateTime)
  • •Database columns are named created and last_updated (snake_case) - never use created_at, created_timestamp, or other variations
  • •Uses Spring Data JPA auditing: @CreatedDate, @LastModifiedDate, @EntityListeners(AuditingEntityListener.class)
  • •Fields are auto-populated by JPA - no manual setting needed

Value Objects:

  • •Use @Embeddable for value objects embedded in entities
  • •Mark with @Immutable (Hibernate annotation) for true immutability
  • •Use @Getter only, never @Setter
  • •Use @NoArgsConstructor(access = AccessLevel.PROTECTED) for JPA, @AllArgsConstructor for construction
  • •Suppress NullAway warnings with @SuppressWarnings(NULL_AWAY_INIT) (constant from com.algorena.common.config.SuppressedWarnings)
  • •Example: OAuthIdentity embeds provider + providerId in User entity

DTOs:

  • •Uses Java records for immutability
  • •Response DTOs contain all public fields (id, created, lastUpdated, etc.)
  • •Request DTOs use Jakarta validation: @NotBlank, @NotNull, @Size
  • •Uses @Nullable for optional fields
  • •Validation messages should be user-friendly: @NotBlank(message = "Bot name is required")
  • •For sensitive data, create separate DTO variants: toPrivateDTO() includes sensitive fields (API keys), toPublicDTO() excludes them

Repositories:

  • •Extends JpaRepository<Entity, Long> - always use Long for ID type, never UUID
  • •Uses method naming conventions: findByField, findByIdAndUserId
  • •Uses @Query with JPQL for complex queries with @Nullable parameters
  • •Parameters do NOT need @Param annotation (Spring Data JPA infers them)
  • •Annotated with @Repository

Services:

  • •Interface + Implementation pattern (FooService + FooServiceImpl)
  • •Implementation uses @Service, @RequiredArgsConstructor
  • •Uses @Transactional (defaults to read-write, readOnly = true for queries)
  • •Injects CurrentUser for user context via currentUser.id()
  • •Throws DataNotFoundException when entities not found
  • •Delegates DTO conversion to Mapper classes - do not implement toDTO methods in services
  • •Use business methods on entities, not direct field manipulation: bot.updateDetails(name, description) not bot.setName(name)
  • •Service interfaces are minimal - just method signatures, no JavaDoc needed for obvious CRUD methods

Mappers:

  • •Located in {domain}/mapper/ package (e.g., com.algorena.bots.mapper.BotMapper)
  • •Use @Component annotation for Spring DI
  • •Pure mapping only - mappers do ONE thing: convert data from one format to another
  • •NEVER inject repositories - if mapping requires loading related entities, the service should fetch them first and pass them to the mapper
  • •Naming convention: {Entity}Mapper or {Domain}Mapper
  • •For public/private views, implement separate methods: toPrivateDTO() and toPublicDTO()
  • •Use @Nullable annotation on methods that can return null
  • •Keep methods simple and stateless - input → output, nothing more

Controllers:

  • •Uses @RestController, @RequestMapping("/api/v1/{resource}")
  • •Uses @PreAuthorize("hasRole('USER')") at class level for authentication
  • •Uses @AllArgsConstructor for dependency injection
  • •Uses OpenAPI annotations: @Tag, @Operation, @Parameter
  • •Follows REST conventions: POST (201), GET (200), PATCH (200), DELETE (204)
  • •Use @PatchMapping for partial updates (not PUT) - aligns with how entities use business methods for targeted updates
  • •Uses @Valid for request body validation
  • •Returns ResponseEntity<T> for type safety
  • •Uses @PathVariable for IDs, @RequestParam for filters
  • •Uses @PageableDefault(size = 20, sort = "created") and @ParameterObject for pagination

Testing:

  • •Unit tests: *Test.java - Pure logic tests with AssertJ
  • •Integration tests: *IntegrationTest.java - Extends AbstractIntegrationTest
  • •Uses AssertJ for assertions: assertThat(), assertThatThrownBy()
  • •Follows Given/When/Then structure with comments
  • •Integration tests use real database via Testcontainers

Common Patterns:

  • •Use CurrentUser service for getting authenticated user ID: currentUser.id()
  • •Security: Verify user owns resource via findByIdAndUserId
  • •Error handling: Throw domain exceptions from com.algorena.common.exception package (singular, not "exceptions"):
    • •DataNotFoundException - 404 when entity not found
    • •BadRequestException - 400 for invalid input
    • •ConflictException - 409 for conflicts
    • •ForbiddenException - 403 for access denied
    • •UnauthorizedException - 401 for authentication failures
    • •InternalServerException - 500 for unexpected errors
    • •BotCommunicationException - for bot endpoint failures
  • •Validation: Jakarta Bean Validation in DTOs, business logic in entities (entities throw IllegalArgumentException)
  • •API keys: Use ApiKeyConverter for encryption (see bots domain)
  • •NullAway: Use @SuppressWarnings(NULL_AWAY_INIT) with constant from com.algorena.common.config.SuppressedWarnings when fields are initialized by JPA/framework

Database Migrations:

  • •Located at backend/src/main/resources/db/migration/
  • •Naming: V{major}_{minor}_{patch}__{description}.sql (e.g., V1_0_7__add_bot_soft_delete.sql)
  • •Column naming conventions (snake_case):
    • •Timestamps: created, last_updated - never created_at, created_timestamp, updated_at
    • •Foreign keys: user_id, bot_id, match_id
    • •Booleans: active, deleted - never is_active, is_deleted
  • •All tables with entities extending BaseEntity must have created TIMESTAMP NOT NULL and last_updated TIMESTAMP NOT NULL
  • •ID Convention: Use BIGSERIAL (Long) for all primary keys - do not use UUID
    • •In Java entities: @Id @GeneratedValue(strategy = GenerationType.IDENTITY) private Long id;
    • •In SQL: id BIGSERIAL PRIMARY KEY
    • •For child tables (joined inheritance): id BIGINT PRIMARY KEY REFERENCES parent_table(id)
  • •Always include proper foreign key constraints with ON DELETE CASCADE where appropriate

Documentation:

  • •Large methods or methods that do complex operations MUST have JavaDoc comments
  • •Methods that are not self-explanatory MUST have JavaDoc explaining their purpose
  • •Small, self-explanatory methods (simple getters, setters, CRUD operations) do NOT need JavaDoc but can have them
  • •When in doubt, add documentation - it's better to over-document than under-document
  • •JavaDoc should explain the "why" and "what", not just repeat the method name
  • •Include @param, @return, and @throws tags for non-trivial methods

Commands

The skill knows these backend commands (from backend/ directory):

  • •./mvnw spring-boot:run - Start dev server (port 8080)
  • •./mvnw test - Run unit tests only
  • •./mvnw verify - Run unit + integration tests
  • •./mvnw test -Dtest=ClassName - Run single test class
  • •./mvnw test -Dtest=ClassName#method - Run single test method

File Structure Template

When creating a new domain, follow this structure:

code
backend/src/main/java/com/algorena/{domain}/
├── controllers/          # REST endpoints
│   └── {Domain}Controller.java
├── application/          # Business logic
│   ├── {Domain}Service.java
│   └── {Domain}ServiceImpl.java
├── domain/              # Entities & value objects
│   └── {Domain}.java
├── data/                # Repositories
│   └── {Domain}Repository.java
└── dto/                 # Data transfer objects
    ├── {Domain}DTO.java
    ├── Create{Domain}Request.java
    └── Update{Domain}Request.java

What to Ask

Before generating code, the skill should:

  1. •Clarify which domain the feature belongs to (create new domain vs extend existing)
  2. •Identify required fields and validation rules
  3. •Determine security requirements (user-owned resources vs public)
  4. •Ask about pagination needs for list endpoints
  5. •Confirm if tests are needed (default: yes for new features)

Adding a New Game

To add a new game type (e.g., Tic-Tac-Toe, Checkers), follow this comprehensive checklist:

1. Update Game Enum

Add the new game to backend/src/main/java/com/algorena/bots/domain/Game.java:

java
public enum Game {
    CHESS,
    CONNECT_FOUR,
    TIC_TAC_TOE  // Add new game
}

2. Backend Game Package Structure

Create backend/src/main/java/com/algorena/games/{newgame}/ with subdirectories:

code
{newgame}/
├── domain/              # Game-specific entities
│   ├── {Game}GameState.java      # Extends AbstractGameState
│   └── {Game}MatchMove.java      # Optional: game-specific move data
├── engine/              # Game logic
│   └── {Game}GameEngine.java     # Implements GameEngine<S, M>
├── application/         # Match execution
│   └── {Game}MatchExecutor.java  # Implements GameMatchExecutor
└── data/               # Repositories
    ├── {Game}GameStateRepository.java
    └── {Game}MatchMoveRepository.java  # Optional

3. Implement Game Engine

Create {Game}GameEngine.java implementing GameEngine<S, M>:

  • •S = Game state type (e.g., ChessGameState)
  • •M = Move type (e.g., String for chess notation, Integer for Connect4 column)
  • •Implement three methods:
    • •startNewGame() - Initialize game state
    • •applyMove(S state, M move, int playerIndex) - Validate and apply move
    • •checkResult(S state) - Return GameResult if game over, null if ongoing
  • •Annotate with @Component for Spring auto-detection
  • •Use GameResult.winner(winnerIndex, loserIndex) or GameResult.draw()
  • •Validate player turns and throw IllegalArgumentException for illegal moves

4. Implement Match Executor

Create {Game}MatchExecutor.java implementing GameMatchExecutor:

  • •Inject: {Game}GameStateRepository, MatchMoveRepository, {Game}GameEngine, BotClientService
  • •Implement getGameType() to return the correct Game enum value
  • •Implement executeSingleMove(Match match):
    • •Load current game state from repository
    • •Check if game is already over via gameEngine.checkResult(state)
    • •Determine current player via getCurrentPlayerIndex(match)
    • •Call bot endpoint via botClientService.requestMove(bot, request)
    • •Validate and apply move via gameEngine.applyMove(state, move, playerIndex)
    • •Save move to database via matchMoveRepository.save(...)
    • •Update and save game state
    • •Return result if game ended
  • •Implement getCurrentPlayerIndex(Match match) to determine whose turn it is
  • •Annotate with @Component for auto-registration in MatchExecutorService
  • •Add JavaDoc explaining game-specific logic

5. Create Database Migrations

Create Flyway migration backend/src/main/resources/db/migration/V{X}_{Y}__{description}.sql:

  • •Add table for game state (e.g., tic_tac_toe_game_states)
    • •Must reference game_states(id) as primary key
    • •Add game-specific columns (board state, turn counter, etc.)
  • •Optionally add table for game-specific move data (e.g., tic_tac_toe_match_moves)
    • •Must reference match_moves(id) as primary key
    • •Add move-specific columns (coordinates, piece type, etc.)
  • •Add indexes for match_id foreign keys

6. Create Domain Entities

Game State Entity - Extends AbstractGameState:

java
@Entity
@Table(name = "{game}_game_states")
@Getter
@NoArgsConstructor
@AllArgsConstructor
public class {Game}GameState extends AbstractGameState {
    // Add game-specific fields (board state, etc.)
    // Add business logic methods for state updates
}

Match Move Entity (optional) - Extends base move:

java
@Entity
@Table(name = "{game}_match_moves")
public class {Game}MatchMove {
    @Id
    private Long id;  // References match_moves(id)
    // Add game-specific move fields
}

7. Create Repositories

java
@Repository
public interface {Game}GameStateRepository extends JpaRepository<{Game}GameState, Long> {
    Optional<{Game}GameState> findByMatchId(Long matchId);
}

8. Write Tests

Create {Game}GameEngineTest.java:

  • •Test startNewGame() returns valid initial state
  • •Test applyMove() with valid moves
  • •Test applyMove() rejects illegal moves with IllegalArgumentException
  • •Test applyMove() rejects wrong player turn
  • •Test checkResult() detects wins, draws, and ongoing games
  • •Use AssertJ assertions: assertThat(), assertThatThrownBy()

Create {Game}MatchExecutorIntegrationTest.java:

  • •Extend AbstractIntegrationTest
  • •Test full match execution with mock bot endpoints
  • •Test error handling (timeouts, invalid moves)
  • •Verify moves and state are saved correctly

9. Frontend Integration

Based on the game registry pattern (see MEMORY.md):

Create frontend/src/components/games/{game}/:

  • •{Game}DetailsComponent.tsx - Display match details
  • •{Game}ReplayComponent.tsx - Interactive replay with controls
  • •{Game}ReplayEngine.ts - Implements calculatePositions(moves) method
    • •Mirror the backend GameEngine.applyMove logic
    • •Return array of position states for each move

Update frontend/src/components/games/registry.ts:

typescript
import { {Game}DetailsComponent, {Game}ReplayComponent } from './{game}'
import { {Game}ReplayEngine } from './{game}/{Game}ReplayEngine'

export const getGameComponents = (gameType: string) => {
  switch (gameType) {
    case 'TIC_TAC_TOE':
      return {
        DetailsComponent: {Game}DetailsComponent,
        ReplayComponent: {Game}ReplayComponent
      }
    // ... other games
  }
}

export const getReplayEngine = (gameType: string) => {
  switch (gameType) {
    case 'TIC_TAC_TOE':
      return new {Game}ReplayEngine()
    // ... other games
  }
}

Use shared hooks for replay functionality:

  • •useReplayControls - Navigation state (current move index)
  • •useReplayAutoplay - Automatic playback
  • •useReplayKeyboard - Arrow keys, Home/End, Space

10. Testing & Verification

  • •Backend: Run ./mvnw verify to test all layers
  • •Frontend: Test replay engine matches backend engine behavior
  • •Integration: Create test bots and run a full match
  • •Verify OpenAPI docs at http://localhost:8080/swagger-ui.html

Tech Stack Context

  • •Java 25, Spring Boot 4.0.2
  • •PostgreSQL with Flyway migrations
  • •NullAway for compile-time null safety
  • •Lombok for boilerplate reduction
  • •OpenAPI/Swagger for API documentation
  • •AssertJ for test assertions
  • •Testcontainers for integration tests
