Entity Command Buffer Helper

Critical Instructions

•Never Structural Change in Job Directly: KHÔNG gọi EntityManager.AddComponent() trong job — phải dùng ECB.
•Choose Right Playback Point: Mỗi ECB system playback tại thời điểm khác nhau. Chọn sai = race condition.
•Parallel Writer Safety: Dùng .AsParallelWriter() trong parallel jobs, với sortKey = unfilteredChunkIndex hoặc entityInQueryIndex.
•Project Convention: Pattern ECB chuẩn hóa cho toàn bộ VisualWorld project.

Core Concepts

What is EntityCommandBuffer?

ECB ghi lại ("record") các thao tác structural change, rồi "playback" chúng tại 1 sync point an toàn trên main thread. Điều này cho phép jobs ghi structural changes mà không gây conflict.

Structural Changes (cần ECB)

•CreateEntity() / DestroyEntity()
•AddComponent<T>() / RemoveComponent<T>()
•SetSharedComponent<T>()
•Instantiate() (clone entity/prefab)
•AddBuffer<T>() / SetBuffer<T>()

Non-Structural Changes (KHÔNG cần ECB)

•SetComponent<T>() trên component đã tồn tại → dùng RefRW<T> trực tiếp
•Write vào NativeArray, DynamicBuffer → trực tiếp trong job

ECB Playback Points

Built-in ECB Systems

code

Frame timeline:
├── BeginInitializationEntityCommandBufferSystem
│     └── ECB playback → structural changes TRƯỚC initialization
├── InitializationSystemGroup
│     └── ... your init systems ...
├── EndInitializationEntityCommandBufferSystem
│
├── BeginSimulationEntityCommandBufferSystem    ← COMMON CHOICE
│     └── ECB playback → structural changes TRƯỚC simulation
├── SimulationSystemGroup
│     ├── ... physics, game logic ...
│     ├── YOUR SYSTEMS HERE
│     └── EndSimulationEntityCommandBufferSystem ← COMMON CHOICE
│           └── ECB playback → structural changes SAU simulation
│
├── BeginPresentationEntityCommandBufferSystem
├── PresentationSystemGroup
│     └── ... rendering ...
└── EndPresentationEntityCommandBufferSystem

Choosing the Right Point

Scenario	Recommended ECB System	Reason
Spawn entity cần xử lý trong frame này	`BeginSimulationECBSystem`	Entity sẵn sàng cho simulation systems
Destroy entity sau khi xử lý xong	`EndSimulationECBSystem`	Đảm bảo tất cả systems đã đọc entity
Spawn entity cho rendering	`BeginPresentationECBSystem`	Entity sẵn sàng cho render systems
Init setup (one-time spawn)	`BeginInitializationECBSystem`	Chạy sớm nhất
Cleanup/despawn sau frame	`EndSimulationECBSystem`	Cuối frame, an toàn

Usage Patterns

Pattern 1: Single-Threaded ECB (SystemAPI.foreach)

csharp

using Unity.Burst;
using Unity.Collections;
using Unity.Entities;
using Unity.Mathematics;
using Unity.Transforms;

/// <summary>
/// Spawn entity từ requests. ECB single-threaded, inline trong System.
/// </summary>
[BurstCompile]
[UpdateInGroup(typeof(SimulationSystemGroup))]
public partial struct SimpleSpawnSystem : ISystem
{
    [BurstCompile]
    public void OnCreate(ref SystemState state)
    {
        state.RequireForUpdate<SpawnRequest>();
    }

    [BurstCompile]
    public void OnUpdate(ref SystemState state)
    {
        // Lấy ECB singleton — KHÔNG tạo bằng new EntityCommandBuffer()
        var ecbSingleton = SystemAPI
            .GetSingleton<BeginSimulationEntityCommandBufferSystem.Singleton>();
        var ecb = ecbSingleton.CreateCommandBuffer(state.WorldUnmanaged);

        foreach (var (request, entity) in
            SystemAPI.Query<RefRO<SpawnRequest>>().WithEntityAccess())
        {
            // Instantiate prefab
            var spawned = ecb.Instantiate(request.ValueRO.Prefab);

            // Set component trên entity MỚI (chưa tồn tại → phải dùng ECB)
            ecb.SetComponent(spawned, LocalTransform.FromPosition(
                request.ValueRO.Position
            ));

            // Add tag
            ecb.AddComponent<ActiveFlag>(spawned);

            // Consume request
            ecb.DestroyEntity(entity);
        }
        // ECB tự playback tại BeginSimulationECBSystem sync point
    }
}

Pattern 2: Parallel ECB (IJobEntity)

csharp

/// <summary>
/// Job xử lý song song với ECB.ParallelWriter.
/// QUAN TRỌNG: sortKey phải unique per entity để đảm bảo deterministic.
/// </summary>
[BurstCompile]
public partial struct ParallelDestroyJob : IJobEntity
{
    public EntityCommandBuffer.ParallelWriter ECB;

    void Execute(
        [ChunkIndexInQuery] int sortKey,    // ← sortKey cho determinism
        Entity entity,
        in HealthComponent health)
    {
        if (health.Current <= 0)
        {
            ECB.DestroyEntity(sortKey, entity);

            // Spawn debris
            var debris = ECB.CreateEntity(sortKey);
            ECB.AddComponent(sortKey, debris, new DebrisData
            {
                Position = /* ... */,
                Velocity = /* ... */
            });
        }
    }
}

// Trong System:
[BurstCompile]
[UpdateInGroup(typeof(SimulationSystemGroup))]
public partial struct DeathSystem : ISystem
{
    [BurstCompile]
    public void OnUpdate(ref SystemState state)
    {
        var ecbSingleton = SystemAPI
            .GetSingleton<EndSimulationEntityCommandBufferSystem.Singleton>();
        var ecb = ecbSingleton
            .CreateCommandBuffer(state.WorldUnmanaged)
            .AsParallelWriter();  // ← PARALLEL WRITER

        state.Dependency = new ParallelDestroyJob
        {
            ECB = ecb
        }.ScheduleParallel(state.Dependency);
    }
}

Pattern 3: ECB with DynamicBuffer

csharp

/// <summary>
/// Thêm buffer elements vào entity mới qua ECB.
/// </summary>
[BurstCompile]
public void SpawnWithBuffer(EntityCommandBuffer ecb, float3 position)
{
    var entity = ecb.CreateEntity();
    ecb.AddComponent(entity, LocalTransform.FromPosition(position));

    // Add buffer và populate
    var buffer = ecb.AddBuffer<NeighborElement>(entity);
    buffer.Add(new NeighborElement { Value = Entity.Null });
}

Pattern 4: Deferred Companion (Tag + Process)

csharp

// Bước 1: Job đánh tag (nhanh, parallel)
[BurstCompile]
public partial struct TagForProcessingJob : IJobEntity
{
    public EntityCommandBuffer.ParallelWriter ECB;

    void Execute([ChunkIndexInQuery] int sortKey, Entity e, in SomeCondition cond)
    {
        if (cond.ShouldProcess)
            ECB.AddComponent<NeedsProcessingTag>(sortKey, e);
    }
}

// Bước 2: System xử lý tagged entities (frame sau)
[BurstCompile]
[UpdateInGroup(typeof(SimulationSystemGroup))]
[UpdateAfter(typeof(TaggingSystem))]
public partial struct ProcessTaggedSystem : ISystem
{
    [BurstCompile]
    public void OnCreate(ref SystemState state)
    {
        state.RequireForUpdate<NeedsProcessingTag>();
    }

    [BurstCompile]
    public void OnUpdate(ref SystemState state)
    {
        var ecb = SystemAPI
            .GetSingleton<EndSimulationEntityCommandBufferSystem.Singleton>()
            .CreateCommandBuffer(state.WorldUnmanaged);

        foreach (var (data, entity) in
            SystemAPI.Query<RefRW<SomeData>>()
                .WithAll<NeedsProcessingTag>()
                .WithEntityAccess())
        {
            // Process...
            data.ValueRW.Processed = true;

            // Remove tag khi xong
            ecb.RemoveComponent<NeedsProcessingTag>(entity);
        }
    }
}

Project-Specific Patterns (VisualWorld)

Voxel Destruction → Debris Spawn

csharp

/// <summary>
/// Khi voxel bị phá hủy (structural collapse), spawn Physics Entity debris.
/// Gom voxels bị phá thành clusters, mỗi cluster = 1 debris entity.
/// </summary>
[BurstCompile]
public partial struct DebrisSpawnJob : IJobEntity
{
    public EntityCommandBuffer.ParallelWriter ECB;
    public Entity DebrisPrefab;

    void Execute(
        [ChunkIndexInQuery] int sortKey,
        Entity chunkEntity,
        in ChunkCoordinate coord,
        in DirtyChunkTag dirty)
    {
        // Scan voxels có Stress > MaxLoad
        // Gom thành clusters
        // Mỗi cluster → ECB.Instantiate(DebrisPrefab)
        // Set position, mass, velocity
    }
}

Phase Change (Solid → Liquid)

csharp

/// <summary>
/// Khi voxel đạt MeltingPoint → đổi State từ Solid sang Liquid.
/// Cần ECB vì thay đổi SharedComponent (material group có thể đổi).
/// </summary>
// Dùng EndSimulation ECB vì thermodynamics chạy trong Simulation

Anti-Patterns (TRÁNH)

csharp

// ❌ SAI: Tạo ECB bằng constructor → phải tự Dispose, dễ quên
var ecb = new EntityCommandBuffer(Allocator.TempJob);
ecb.Playback(entityManager);
ecb.Dispose(); // Nếu quên → memory leak

// ✅ ĐÚNG: Dùng Singleton pattern → tự động playback & dispose
var ecb = SystemAPI.GetSingleton<BeginSimulationECBSystem.Singleton>()
    .CreateCommandBuffer(state.WorldUnmanaged);

// ❌ SAI: Dùng EntityManager trực tiếp trong Job → crash
void Execute(int i) {
    entityManager.CreateEntity(); // KHÔNG ĐƯỢC!
}

// ❌ SAI: sortKey = 0 cho tất cả → non-deterministic
ECB.DestroyEntity(0, entity); // Luôn dùng chunkIndex hoặc entityInQueryIndex

// ❌ SAI: Structural change trên main thread giữa 2 jobs → sync point ngầm
state.EntityManager.AddComponent<Tag>(entity); // Forces sync → kills perf

Validation Checklist

• ECB lấy từ Singleton, không new EntityCommandBuffer()
• Parallel jobs dùng .AsParallelWriter() với sortKey
• sortKey = [ChunkIndexInQuery] hoặc tương đương, không hardcode 0
• Playback point phù hợp (Begin/End + Init/Sim/Present)
• Không gọi EntityManager structural methods trong jobs
• Không gọi EntityManager structural methods giữa job scheduling
• ECB commands referencing newly created entities sử dụng returned Entity handle
• System có [UpdateInGroup] và ordering đúng relative to ECB system
